Description
Specification
Size Guide
Bike Size
Regular / Large
User Height Range
Step-Thru / Regular: 5’2” – 5’11”
Step-Thru / Large: 5’10” – 6’5”
High-Step / Regular:5’2” – 5’11”
High-Step / Large: 5’10” – 6’5”
Step-Thru / Large: 5’10” – 6’5”
High-Step / Regular:5’2” – 5’11”
High-Step / Large: 5’10” – 6’5”
Frameset
Frame
Triple-Butted Aluminum Alloy
Fork
RST Hydraulic suspension 100mm travel with Lock-out, Nutted
Electronics
Motor Hub48V, 750W, 90Nm
BatteryRemovable 48V, 14.7Ah (705.6Wh), IPX7, Certificated by UL 2271
CellSamsung/LG 21700 cell, Certificated by UL 2580
Charger48V, 3.0A Fast Charger
Display3.5″ Full color, High brightness, Bluetooth, Adjustable angle
SensorTorque and Cadence Sensor
USB PortUSB Type-C phone charge
Throttle AssistTrigger-control, removable
Pedal Assist3 Riding Modes x 5 PAS Levels
Walk Mode2.9 MPH
Front LightLight sensing 130 Lux /500 LM high-output integrated LED, adjustable angle
Rear LightBraking Indicator, turn signal, rear light steady/flash, integrated with rear rack
App & Apple Find My™APP OTA & Find My
Speed & Range
*A 187-lb rider using PAS 1 in Eco mode on flat roads.
Max Speed (Default)
20 MPH
Max Speed Adjustable Range
12~28 MPH
Class
1/2/3
Throttle Range
45 Miles
Pedal Assist Range
65 Miles
Drivetrain
Chainrings
48T
Crankset
Aluminum Alloy, 165mm
Freewheel
8-speed, 11-40T
Chain
8-speed
Rear Derailleur
SHIMANO 8-speed
Shift Lever
SHIMANO 8-speed
Brake
Brake
Tektro Hydraulic Disc Brake
Rotors
203mm Front/180mm Rear
Brake Levers
Aluminum Alloy, with power cutoff
Wheel
Rims
Aluminum alloy
Front Hub
Aluminum alloy, nutted
Tire
KENDA 26×4.0″ eBike puncture-resistant tires
Cockpit
Handlebar
Aluminum Alloy, Φ31.8mm, 680mm(R)/700mm(L)
Grips
Durable ergonomic grips, lockable
Stem
Adjustable, Aluminum Alloy, Φ31.8mm, 60mm(R)/90mm(L)
Saddle
VELOTRIC comfort ergonomic seat
Seatpost
Aluminum Alloy, Φ30.9mm, Suspension
Clamp
Aluminum Alloy, quick release
Supports
Fenders
Front and rear full coverage
Rear Rack
MIK HD Compatible Alloy
Pedals
Plastic
Kickstand
Aluminum Alloy, included, rear mount
Weight & Load
Bike Weight
75lbs
Max Bike Load
505lbs
Rear Rack Load Capacity
66lbs
Certification
UL Certification
UL 2849
ISO Standard
ISO 4210
