Description
Specs
Details
-
Platform
-
Model Name
Quick 3 -
Model Code
C3105GU
Frameset
-
Frame: Quick, SmartForm C3 Alloy, tapered head tube, Straightshot hidden cable routing, post mount disc, rack/fender/Si kickstand mounts
-
Fork: Steel, ISO disc mount, 100x9mm QR, 1-1/8″ steerer, fender mounts,
-
Headset: Sealed Bearing, integrated, 1-1/8″
Drivetrain
-
Rear Derailleur: Shimano Essa U2000, 8-speed
-
Shifters: Shimano Essa, RapidFire, 8-speed
-
Chain: KMC X8, 8-speed
-
Crank: Shimano Essa, 40T
-
Rear Cogs: Shimano HG400, 11-45, 8-speed
-
Bottom Bracket: Shimano UN101, square taper
Brakes
-
Brakes: Shimano MT200 hydraulic disc, 160/160mm RT10 centerlock rotors
-
Brake Levers: Shimano MT-200 hydraulic disc
Wheels
-
Rims: Cannondale DC 4.0 Disc, double wall w/eyelet, 32h
-
Spokes: Stainless Steel, 14g
-
Tire Size: 35
-
Wheel Size: 700c
-
Hubs: (F) Shimano QC300, 9x100mm, centerlock, QR / (R) Shimano QC300, 9x135mm, centerlock, QR
-
Tires: Schwalbe Spicer Plus, 700x35c
Components
-
Handlebar: Cannondale 3 Riser, 6061 Alloy, 18mm rise, 8° back, 4° up, 680mm
-
Stem: Cannondale 3 Intellimount, Alloy, 31.8mm, with Universal Phone Clamp and SP-Connect SPC+ mount
-
Grips: Ergon GA30 ergonomic, lock-on
-
Saddle: Selle Royal Vaia Moderate
-
Seatpost: Cannondale 3, 6061 Alloy, 27.2x350mm (XS-LG), 400mm (XL-2XL)
Connectivity
-
Components: SP-Connect Universal Phone Clamp, SP-Connect SPC+ mount, Cannondale AppTag
Please note that, based on component availability and other factors, specifications are subject to change without notice.
