Description
Top Tube 20.5”
Chain Stay 13.75”
Head Tube 75º
Seat Tube 72º
Frame Chromoly front triangle w/ integrated headtube and seat-post clamp
Fork Hi-ten steel w/ chromoly steerer tube, built-in bearing race, internally threaded pre-load bolt, tapered legs
Handlebar 8.8” rise, hi-ten steel
Grips DK Tsuka with press-in bar plugs
Stem DK Jump top load, 53mm reach
Headset Sealed integrated
Brake Wise alloy U-brake
Lever Wise hinged alloy
BB 19mm sealed Mid
Cranks Wise tubular chromoly 3-piece, 170mm, 8-spline spindle
Sprocket DK Replica 26-tooth, alloy
Chain KMC Z-510
Pedals DK Blender PC platform
Rims Wise Rectrix2, Double wall, 36mm wide, 36-hole
Front Hub Alloy, sealed, 3/8” axle
Rear Hub Alloy, sealed, 14mm axle, 9-tooth driver
Tires Kenda 20×2.3”, 60psi
Seat DK 1-piece padded seat/post combo
Seat Post Integrated, 25.4mm, alloy
Extra Features 3D head tube badge
Seat Post Clamp Integrated
Weight 25.4 lbs
