Description
-
Frame: Habit HT, SmartForm C2 Alloy, tapered headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA 73, 12mm thru axle, Boost 148, 55mm chainline, UDH hanger.
-
Fork: SR Suntour XCM 34 LO Boost 29, 130mm travel, 15x110mm thru axle, tapered alloy steerer, 44mm offset
-
Headset: Integrated Sealed Bearing, Tapered
Drivetrain
-
Rear Derailleur: Shimano CUES U6000
-
Shifters: Shimano CUES U6000, 10-speed
-
Chain: KMC X10, 10-speed
-
Crank: Prowheel, 30T
-
Rear Cogs: Shimano LG300, LinkGlide, 11-48, 10-speed
-
Bottom Bracket: ProWheel BSA 73
Brakes
-
Brakes: Shimano MT200 hydraulic disc, 180/180mm RT10 rotors
-
Brake Levers: Shimano MT200 hydraulic disc
Wheels
-
Front Hub: Shimano TC500, 15x110mm
-
Rear Hub: Shimano TC500, 12x148mm
-
Rims: WTB STX i25 TCS, 32h, tubeless ready
-
Spokes: Stainless Steel, 14g
-
Tire Size: 2.3
-
Wheel Size: 29
-
Tires: (F) WTB Breakout, 29×2.3″, Comp DNA / (R) WTB Trail Boss, 29×2.25″, Comp DNA
Components
-
Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
-
Stem: Cannondale 3, 6061 Alloy, 31.8, 0°
-
Grips: Cannondale Locking Grips
-
Saddle: Cannondale Ergo XC
-
Seatpost: TranzX dropper, internal routing, 31.6, 100mm (S), 120mm (M), 130mm (L-XL)
